Absolute Encoders

Industrial encoders absolute

Absolutely universal – reliable position feedback without referencing, singleturn and multiturn technology

• Magnetic or optical sensing – always the best technology for your application

• Wide and convenient selection among all relevant signal interfaces & shaft versions

• Compact designs from 28 mm for time- & space-saving installation

28 mm – integrated interface, robust magnetic

• Solid shaft

• CANopen and analog

• Redundant variants

30 mm – integrated interface, robust magnetic

• Solid shaft, blind hollow shaft

• SSI, CANopen

• Shaft diameter from 5 to 8 mm

• Angular accuracy up to ±0.15˚

• Radial or axial connector and cable connection

• 36 mm – integrated interface, robust magnetic

• Solid shaft, blind hollow shaft or bearingless kit

• SSI, CANopen, CANopen Lift

• Additional incremental signals

• Up to 15 mm shaft diameter

• Angular accuracy up to ±0.15˚

  58 mm – integrated interface, robust magnetic

• Solid shaft, blind hollow shaft or bearingless kit

• PROFINET, EtherCAT, EtherNet/IP, SSI, CANopen, CANopen Lift

• Additional incremental signals

• Industry 4.0 and IoT ready via PROFINET or OPC UA

• Angular accuracy up to ±0.15°

• Design 58 mm or 36 mm

• Solid shaft, blind hollow shaft or bearingless kit

• CANopen, SAE J1939 and analog

• Applicable up to PLd (ISO 13849)

• E1 compliant design

• CX (C5-M) corrosion protection

• Redundant variants

58 mm – compact precise optical

• Solid shaft, blind or through hollow shaft

• Optical sensing, high accuracy of up to ± 0,01°

• PROFINET, EtherCAT, EtherNet/IP

• Industry 4.0 and IIoT ready via OPC UA

• Extremely small installation depth

Industrial encoders absolute

• 13 bit singleturn / 12 bit multiturn resolution

• Extremely compact multiturn encoder

• BiSS C certified interface

• SSI

• 58 mm integrated interface – precise optical

• Solid shaft, blind or through hollow shaft

• SSI, SSI with Incremental

• Variants with stainless steel housing

58 mm modular bus cover

• Shaft, blind or through hollow shaft

• CANopen, Profibus

• M12 connector or user-assembled cable

• Gear factor function

• Simple wiring for easy replacement

Redundant sensing

• Double position sensing

• Redundant signal processing and output interface (depending on version)

• Design 58 mm

• CANopen, Analog

Safety-certified absolute encoder for Mobile Machines

• Enhanced machine performance

• Easiest machine integration

• Designed for maximum machine uptime

• SIL2 / PLd-certified safety encoder

Multiturn encoders – compact, robust, precise

• Single and multiturn positioning

• CANopen, SAE J1939 & SSI interface

• Extremely robust even under the toughest conditions in outdoor use

• Protection class up to IP69K, additionally thermal shock dunk tested

• Immune to shock and vibration

• Installation depth only 22 mm

 benefits

• For every application the right product

  • Ultra-precise optical encoders for high speed applications or magnetic encoders with a maximum of robustness and lifetime.

• Easy product selection with maximum flexibility

  • Broad portfolio, all relevant shaft, flange and connector variants, all relevant interfaces

• From compact to large

  • Ø28 mm housings up to Ø50 mm hollow shaft designs, Profinet encoders with shallowest mounting depth of merely 47 mm

• Supporting all relevant controller

  • Varied interfaces: SSI, BiSS, all relevant fieldbus and realtime Ethernet interfaces and high-quality incremental signals

• Robust and durable also in harsh environments

  • Bearingless or hermetically sealed IP 69K variants, EAM R-Series with CX (C5-M) corrosion protection and E1 compliant design

• Industry 4.0 – IoT ready

  • Access to parameters and additional information via PROFINET & OPC UA, Cloud Service compatible for process optimization, e.g. preventive maintenance

Applications

Broad portfolio for detection of position and speed in many different applications

• Packaging

• Medical industry

• Handling and mounting systems

• Wood, plastic or metal processing

• Production and processing of paper and board

• Textile machinery

• Elevators

• Mobile automation

• Forklift trucks

• Wind energy plants

• Harbour cranes

Incremental Encoder

Long Spa

Incremental Heavy Duty encoders provide information on speed and angular position. Their resolution is expressed as the number of pulses (square-wave signals) and the sinusoidal (Sin Cos) signals per revolution, which the rotary encoder transmits to the controller with each revolution of its shaft. Sin Cos signals can be interpolated in a controller or in a controller to increase the resolution.

The upstream control identifies the current speed by the pulse numbers counted within a defined time period, while the current position information is identified by the counted pulses or Sin Cos periods, respectively. At system power-on, a reference travel is required since the encoder information may have been lost during power off and further to eliminate any incorrect result caused by any shaft rotation performed during power-off.

HeavyDuty encoders with leading all-round protection and new smart functions

Outstanding service life and system uptime

Unique protection against dust, moisture, overvoltage and miswiring

Easy parameterization of speed and service life monitoring

Compact design and sealed, user-friendly field termination

The selected altAttribute does not exist!

The incremental HeavyDuty standard

Blind hollow shaft, cone shaft and solid shaft

500 ... 5000 ppr

Operating temperature -40 ... +100 °C

Particularly cost-efficient E -series

Redundant sensing

Twin encoder combination

Integrated digital DSL speed switch

Combined with mechanical FSL speed switch

EMS function monitoring for maximum system uptime

benefits

Robust mechanics, reliable electronics, easy installation: Our incremental HeavyDuty encoders reliably operate in 24/7 operation permanent under the toughest conditions. They make significant contributions to avoid failures and high standstill cost, and thus give a key contribution to the high availability of your machine or system.

• Highest availability and unrivalled durability under harshest ambient conditions

  • Proven HeavyDuty design, double-sided bearing setup, HeavyDuty connection technology, highly robust sensing

• Failure safety in any environment

  • Extremely durable aluminum or stainless steel housing, outstanding corrosion protection up to category CX (C5-M), long-term stable sealing concept, operating temperature up to -40 ... +100 °C (as option -50 °C)

• Efficient protection against bearing damage

  • Double-sided bearing setup (where possible), generously dimensioned bearings with large bearing spacing, high bearing load reserve for large radial / axial shaft loads, no inductive shaft currents due to hybrid bearings with ceramic balls

• Improved control and process quality in the application

  • Interference-proof, precise sensing with Opto-ASIC, best electromagnetic compatibilty

• Less drive heating and higher energy efficiency

  • Perfect sinusoidal signal quality by LowHarmonics® technology, SinCos signals with negligibly small harmonic component

• Reliable signal transmission over long distances

  • Powerful output drivers for cable lengths up to 350 m (HTL-P) and 550 m (TTL), signal transmission via optical fiber up to 1500 m

    Applications

  • Incremental HeavyDuty encoders are designed for maximum robustness and durability, with enormous mechanical reserves to ensure reliable performance even in the harshest environments:

    • Steelworks and rolling mills

    • Port installations and crane technology

    • Hoists and lifting platforms

    • Underground and open pit mining

    • Materials handling equipment

    • Large drives and generators

    • Wind turbines

Linear Encoder

Mobile Shelving

Linear magnetic encoders

Non-contact length measuring operations, cost-efficient and precise

• Non-contact, wearfree magnetic sensing technology

• Impervious to soiling and resistant against vibration

• Extended life span thanks to robustness and durability in extreme conditions

• Maximized machine and system uptime

Incremental – design 10 mm

• Sensing head and adhesive magnetic tape

• Robust magnetic sensing

• Incremental output signals

• HTL / TTL with index pulse

• Resolution up to 5 μm

• Easy and reliable linear travel measurements

  • Quick integration and flexibility, reliable operation

• Space-saving attachment and easy handling

  • 10 mm sensing head and magnetic tape, the large installation tolerance allows for max. 0.6 mm air gap between sensor and tape

• Virtually unlimited measuring length

  • Incremental output signals, magnetic tape in individualized lengths

• Durable and unaffected by dirt, moisture, shock and vibration

  • Non-contact, wearfree sensing principle, protection IP 67

• Robust even in extreme outdoor environment

  • Masking tape of stainless steel to protect the magnetic tape against mechanical abrasion and sunlight

Applications

Travel measurement and positioning of machine parts and slides, processing units and stop positions at

• Wood and metal processing

• Laser or water jet cutting facilities

• Electric or pneumatic linear drives

• Bottling stations

• Solar energy plants.
